VM2030 is a Vibration Meter, optimized for remotely
real-time vibration monitoring.It reports measurement results to internet server through 4G Modem or Internet, or to local PC.

Key Advantages

• 3D velocity sensor
• High precision A/D convertor, provide high resolution
• Remotely configurable
• Interval max reading mode and Trigger event mode, working in the meantime
• Self-test Function
• Sending data/configuration by RS232 and USB
• Integrated with Vibration Real-time Monitoring Management Software Platform
• Support off-line recording, for 10 days by internal battery

Applications

• Building integrity and construction safety check
• Structure health monitoring (SHMS)
• Blast monitoring and analyis
• Seismic observation
• Environment monitoring

Specification

Parameter	Value
Measurement Range	110/220/440 mm/s
Resolution	0.00085mm/s 0.0017mm/s 0.0034mm/s
Frequency Range	0 - 250 Hz
Sampling Rate	100Hz-5kHz
Recording Time	1-90s
Accuracy	3 % FS
Trigger Level	0.06-440mm/s
Channel	3 Seismic Channels
Storage	32GB
Rechargeable Battery	3.7V 12000mAh
Dimensions	195x90x60 mm(Logger) 120x120x50 mm(Sensor)
Housing Material	Plastic(Logger) Aluminium Alloy(Sensor)
Net Weight	1.8kg
Protection	IP67
